1×1Port
¥ 0.00立即购买
-
RJ1D11-000451-10
RJ3D11-00451-10
EMI Fingers:NO
LEDS（L/R）：G/Y
Lnsertion Loss,1-65MHZ:-1
Return Loss(db TYP)100:1-10MHZ:-20,30MHZ:-16,30-60MHZ:-12;60-80MHZ:-10
Hipot(vrms min)@60HZ 1MIN:2250¥ 0.00立即购买
-
RJ1D11-00651-10
RJ1D11-00651-10
Turns Ratio (圈比): TX（1CT:1），RX（1CT:1）
LEDS（L/R）：G/Y
Lnsertion Loss,1-65MHZ:-1
Return Loss(db TYP)100:1-10MHZ:-20,10-30MHZ:-16,30-60MHZ:-12;60-80MHZ:-10
Hipot(vrms min)@60HZ 1MIN:2250¥ 0.00立即购买
-
RJ1D11-11011-01
RJ1D11-11011-01
Turns Ratio (圈比): TX（1CT:1），RX（1CT:1）
LEDS（L/R）：G/Y
Lnsertion Loss,1-65MHZ:-1
Return Loss(db TYP)100:1-10MHZ:-20,10-30MHZ:-16,30-60MHZ:-12;60-80MHZ:-10
Hipot(vrms min)@60HZ 1MIN:1500¥ 0.00立即购买
-
RJ1D11-11011-10
RJ1D11-11011-10
Turns Ratio (圈比): TX（1CT:1），RX（1CT:1）
LEDS（L/R）：G/Y
Lnsertion Loss,1-65MHZ:-1
Return Loss(db TYP)100:1-10MHZ:-20,10-30MHZ:-16,30-60MHZ:-12;60-80MHZ:-10
Hipot(vrms min)@60HZ 1MIN:2250¥ 0.00立即购买
-
RJ1D11-11210-10
RJ1D11-11210-10
Turns Ratio (圈比): TX（1CT:1），RX（1CT:1）
LEDS（L/R）：NO
Lnsertion Loss,1-65MHZ:-1
Return Loss(db TYP)100:1-10MHZ:-20,10-30MHZ:-16,30-60MHZ:-12;60-80MHZ:-10
Hipot(vrms min)@60HZ 1MIN:1500¥ 0.00立即购买
-
RJ1D11-11211-10
RJ1D11-11211-10
Turns Ratio (圈比): TX（1CT:1），RX（1CT:1）
LEDS（L/R）：G/Y
Lnsertion Loss,1-65MHZ:-1
Return Loss(db TYP)100:1-10MHZ:-20,10-30MHZ:-16,30-60MHZ:-12;60-80MHZ:-10
Hipot(vrms min)@60HZ 1MIN:2250¥ 0.00立即购买
-
RJ1D11-26211-10
Turns Ratio (圈比): TX（1:1CT），RX（1CT:1）
LEDS（L/R）：G/Y
Lnsertion Loss,1-65MHZ:-1
Return Loss(db TYP)100:1-10MHZ:-20,10-30MHZ:-16,30-60MHZ:-12,60-80MHZ:-10
Hipot(vrms min)@60HZ 1MIN:1500¥ 0.00立即购买
-
-
-
LP06271G
Turns Ratio (圈比): 1CT:1CT
Rise Time:4.2
Primary ET-Constant:5.0
Hi Pot Vrms:1500¥ 0.00立即购买
-
LP12715G
Turns Ratio (圈比): 1:2CT & 1:2CT
OCL(电感）(mH MIN)：20
LL(uH MAX):5
CW/W(pF MAX):130¥ 0.00立即购买
-
LP16008G
Turns Ratio (圈比):( A:1:1),(B:1:1)
OCL(电感）：22
CW/W(pF MAX):(A&B:100)
DI dcC(mA MAX):1750¥ 0.00立即购买
-
LP16076G
Turns Ratio (圈比): 1:1.15CT&1CT:2CT
OCL(mH Min)(电感）：1.20&1.20
LL(μH MAX）：0.60&0.60
DCR Pri（Ω MAX）：0.70&0.70¥ 0.00立即购买
-
LP12841G
Turns Ratio (圈比):1CT:2CT & 1CT:2CT
OCL(电感）mH MIN：1.20 & 1.20
LL(漏感）：0.8uH&0.8uH
CW/W（电容）：50pF&50pF
DCR（直流电阻）：1.00&1.00
Primary Pin:12-10,4-6¥ 0.00立即购买
-
LE06606G
Turns Ratio (圈比): 1.00 ± 2%
INDUCTANCE(OCL) AT 100KHz 0.1V: 135μH MIN, 370μH MAX（-40℃≤T≤-30℃）;150μH MIN, 370μH MAX（-30℃≤T≤125℃）
OPERATING TEMP: -40℃TO +125℃¥ 0.00立即购买
-
LE06603G
Turns Ratio (圈比): 1.00 ± 2%
DC RESISTANCE: (TRANSFORMER SIDE: 0.35 OHMS MAX);(CM CHOKE SIDE: 0.80 OHMS MAX)
COMMON MODE REJECTION RATIO: 1-10 MHz:-35 db MIN;10-100 MHz:-20 db MIN
OPERATING TEMP: -40℃TO +125℃¥ 0.00立即购买
-
LE48011G
Turns Ratio (圈比): 1:1CT
Insertion Loss (dB MAX):(100KHz:-1.2),(1-125MHz:-0.2-0.002*fˆ1.4)
Return Loss (dB MAX):(0.1-40MHz:-16),(40-100MHz:-10+20*LOG10（f/80）)
Hipot(Vrms Min)1MIN:1500¥ 0.00立即购买
-
-
-
PC22147NL
FREQUENCY:ATTENUATION
Insertion Loss:(5 MHz:-1.0 dB MAX),(65 MHz:-1.0 dB MAX),(100MHz:-2.0 dB MAX),(200MHz:-2.0 dB MAX)¥ 0.00立即购买
-
PC22040NL
IMPEDANCE RATIO:1:1
TURNS RATIO (Pri:Sec):1:1
BANDWIDTH:(3.0dB:1.5-500MHz),(2.0dB:2.5-400MHz),(1.0dB:5-350MHz)
INSERTION LOSS@MIDBAND:0.90 dB（TYP)¥ 0.00立即购买
-
PE21597NL
¥ 0.00立即购买
-
PE24246NL
Turns Ratio (圈比):1.11:1
OCL Line (1-4) with(2-3) shorted 10kHz, 100mVrms (uH±10%):430
THD@ 30kHz 3.0Vrms (dB Min):-62.0¥ 0.00立即购买
-
PE24285NL
Turns Ratio (圈比):1.4:1
OCL(电感）(1-4) with(2-3) shorted 10kHz:430¥ 0.00立即购买
-
PE24289NL
¥ 0.00立即购买
-
PG20184NL
TURNS RATIO:1:1
Pri-Sec Isolation:1500 Vrms
Primary Inductance (μH MIN):1200
Leakage2 Inductance (μH MAX):0.5¥ 0.00立即购买
-
PG20185NL
TURNS RATIO:1:1
Pri-Sec Isolation:1500 Vrms
Primary Inductance (μH MIN):980
Leakage2 Inductance (μH MAX):0.75¥ 0.00立即购买
-
-
-
PB2-1518
Test Condition(测试条件):100KHz/0.1V
Inductance电感（μH）:3.3
Tolerance公差（%）:±20
DC Resistance 直流电阻（Ω）Max:0.068
Rated Current 额定电流（A）Max:1.95¥ 0.00立即购买
-
PB2-1528
Test Condition(测试条件):100KHz/0.1V
Inductance电感（μH）:1.0
Tolerance公差（%）:±20
DC Resistance 直流电阻（Ω）Max:0.025
Rated Current 额定电流（A）Max:2.2¥ 0.00立即购买
-
PB2-1428
Test Condition(测试条件):100KHz/0.1V
Inductance电感（μH）:1.5
Tolerance公差（%）:±20
DC Resistance 直流电阻（Ω）Max:0.025
Rated Current 额定电流（A）Max:2.10¥ 0.00立即购买
-
PB2-1418
Test Condition(测试条件):100KHz/0.1V
Inductance电感（μH）:1.0
Tolerance公差（%）:±20
DC Resistance 直流电阻（Ω）Max:0.045
Rated Current 额定电流（A）Max:1.72¥ 0.00立即购买
-
PB2-1328
Test Condition(测试条件):100KHz/0.1V
Inductance电感（μH）:10
Tolerance公差（%）:±20
DC Resistance 直流电阻（Ω）Max:0.092
Rated Current 额定电流（A）Max:0.500¥ 0.00立即购买
-
PB22174NL
Inductance @Irated (uH MIN):2
Irated(A):8.3
DCR (mΩ MAX):7.6
Inductance @ 0Adc (uH±10%):2.2¥ 0.00立即购买
-
LE24408G
Turns Ratio (圈比): 1:1±2%
Return Loss(db TYP)100:1-40MHz:-16db MIN;40-100MHz:-10+20*LOG10（f/80MHz）db MIN
Crosstalk:1-10MHz:-50db MIN;30-100 MHz:-55+24*LOG10（f/10MHz）db MIN
DIFFRENTIAL TO COMMON MODE REJECTION:2MHz:-50db MIN;30-100MHz:-43+22*LOG10（f/30MHz）db MIN
OPERATING TEMPERATURE:-40℃~ +85℃
Return Loss(db TYP)100:1-40MHz:-16db MIN;40-100MHz:-10+20*LOG10（f/80MHz）db MIN
Crosstalk:1-10MHz:-50db MIN;30-100 MHz:-55+24*LOG10（f/10MHz）db MIN
DIFFRENTIAL TO COMMON MODE REJECTION:2MHz:-50db MIN;30-100MHz:-43+22*LOG10（f/30MHz）db MIN
OPERATING TEMPERATURE:-40℃~ +85℃
